Pflitsch UNI Dicht fire protection - cable glands
- UNI Dicht fire protection metal cable glands for installations with high fire protection requirements. Versions available in nickel-plated brass or stainless steel, with T80s or S55 sealing insert, IP68 protection class (up to 10 bar), EN 45545-2/-3
Pflitsch UNI Dicht fire protection
Pflitsch cable glands from the UNI Dicht series for fire protection applications are available in two material versions: nickel-plated brass or AISI 303 stainless steel. They provide IP68 protection (up to 10 bar) and are equipped with an HNBR O-ring and a T80s or S55 sealing insert – the choice of sealing material depends on the application requirements. The glands meet the requirements of EN 45545-2: HL3 and EN 45545-3: E20 and are designed for environments with an increased risk of fire. Metric thread in accordance with EN 60423. Operating temperature range depending on the sealing material used: from -40°C to +130°C (T80s) or from -55°C to +180°C (S55).
Features of UNI Dicht cable glands for fire protection:
- Nickel-plated brass or AISI 303 stainless steel housing
- HNBR seal and T80s or S55 insert (depending on version)
- IP68 protection rating (up to 10 bar)
- Hazard class HL3 according to EN 45545-2
- Fire resistance E20 according to EN 45545-3
- Operating temperature range: from -40°C to +130°C (T80s) or from -55°C to +180°C (S55)
- Metric thread according to EN 60423
Applications
- Installations in rail vehicles
- Transport and infrastructure systems
- Areas with high fire protection requirements
- Installation technology requiring a wide operating temperature range
| Part No. | Thread A |
Thread length D [mm] |
Clamping range max–min ø [mm] |
Packaging |
|---|---|---|---|---|
| 21049 | M10x1.5 | 5.0 | 6.5 – 4.0 | 50 |
| 21249 | M12x1.5 | 5.0 | 6.5 – 4.0 | 50 |
| 21650 | M16x1.5 | 6.0 | 9.5 – 4.0 | 50 |
| 22052 | M20x1.5 | 6.5 | 10.5 – 5.0 | 50 |
| 22554 | M25x1.5 | 7.5 | 20.5 – 17.0 | 25 |
| 23254 | M32x1.5 | 8.0 | 20.5 – 17.0 | 25 |
| 24055 | M40x1.5 | 8.0 | 25.0 – 17.0 | 5 |
| 24056 | M40x1.5 | 9.0 | 28.0 – 24.0 | 5 |
| 25056 | M50x1.5 | 10.0 | 36.0 – 32.0 | 5 |
| 26358 | M63x1.5 | 10.0 | 44.0 – 36.0 | 5 |
To download
Producer
Product code
UNI Dicht fire protection
Material
Nickel-plated Brass
, Stainless Steel AISI 303
Insert material
T80s
, S55
Thread
M10
, M12
, M16
, M20
, M25
, M32
, M40
, M50
, M63
Sealing range in millimeters
4-6.5 mm
, 6.5-9.5 mm
, 5-8 mm
, 7-10,5 mm
, 9-13 mm
, 11.5-15.5 mm
, 14-18 mm
, 17-20.5 mm
, 20-25 mm
, 24-28 mm
, 27-32 mm
, 32-36 mm
, 36-40 mm
, 39-44 mm
Thread length in millimeters
5
, 6
, 6.5
, 7.5
, 8
, 9
, 10
Ingress Protection
IP68
Application features
Fire-resistant
Colour
Unpainted
Insert color
Black
Temperature range
-40...+130°C
, -55...+180°C
