Flexa RQF2-M - connector for corrugated tubings
- RQF2-M is a Flexa connector designed for conduits. The product is made of polyamide (PA) and equipped with a quick connector (FLEXAquick flange technology).
Flexa RQF2-M
Flexa RQF2-M is a plastic connector from the FLEXAquick® system, designed for ROHRflex® protective pipes. It features a 90° flange and a flange gasket. It is made of polyamide (PA), which is resistant to oils, gasoline, and a wide range of acids and solvents. The operating temperature range of the connector is from -40°C to +120°C.
Connector features
- resistant against oil and benzine
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Applications
- machine and plant constructions
- automation
- electrical installations
RQF2-M - plastic connector with 90°, temperature range -40...+120°C, metric thread
| FLEXA No. | Colour | Thread type | B [mm] |
C [mm] |
D [mm] |
G [mm] |
Ø [mm] |
Ø E [mm] |
H [mm] |
F [mm] |
Weight [kg|100] |
PU [pcs.] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15020071225 | Black | M25 x 1,5 | 46,0 | 32,0 | 36,0 | 5,4 | 29,5 | 13,0 | 15,5 | 0,660 | 50 | |
| 15020071232 | Black | M32 x 1,5 | 63,0 | 46,0 | 52,0 | 6,6 | 37,0 | 16,5 | 20,0 | 1,480 | 25 | |
| 15020071240 | Black | M40 x 1,5 | 67,0 | 55,0 | 54,0 | 36,0 | 6,6 | 29,5 | 16,0 | 18,5 | 1,900 | 10 |
| 15020071250 | Black | M50 x 1,5 | 86,0 | 64,0 | 73,0 | 30,0 | 6,6 | 55,0 | 17,0 | 20,0 | 2,500 | 10 |
| 15020071263 | Black | M63 x 1,5 | 86,0 | 70,0 | 73,0 | 30,0 | 6,6 | 68,0 | 17,0 | 20,0 | 2,500 | 5 |
| 15020071025 | Grey | M25 x 1,5 | 46,0 | 32,0 | 36,0 | 5,4 | 29,5 | 13,0 | 15,5 | 0,660 | 50 | |
| 15020071032 | Grey | M32 x 1,5 | 63,0 | 46,0 | 52,0 | 6,6 | 37,0 | 16,5 | 20,0 | 1,480 | 25 | |
| 15020071040 | Grey | M40 x 1,5 | 67,0 | 55,0 | 54,0 | 36,0 | 6,6 | 45,0 | 16,0 | 18,5 | 1,900 | 10 |
| 15020071050 | Grey | M50 x 1,5 | 86,0 | 64,0 | 73,0 | 30,0 | 6,6 | 55,0 | 17,0 | 20,0 | 2,500 | 10 |
| 15020071063 | Grey | M63 x 1,5 | 86,0 | 70,0 | 73,0 | 30,0 | 6,6 | 68,0 | 17,0 | 20,0 | 2,500 | 5 |
